SATLINK Satellite Meter WS7009SE

Satlink Satellite meter WS 7009 SE - 2019 model Second Edition , with 500 Mhz Novatek / 1 GB of RAM

with Spectrum analyzer - and DVB-S/S2 DVB-T/T2 , Blind - Scan and Unikabel - Measurement

Model with keyboard light and torch function

DIGITAL SIGNAL FINDER ( DVB-S/S2 + DVB-T/T2 ) HD FTA

The Satlink WS -7009 HD SE is a professional measuring instrument for all satellites - reception facilities according to European standards.

It is suitable for new installation of a satellite dish to quickly find the desired DVB-S/DVB-S2 satellites as well as to validate existing satellite - receiver systems .

It is suitable for new installation of a terrestrial DVB- TAntenne to quickly find a desired signal DVB-T/T2 and systems to validate existing DVB -T receiver.

The Signal - You can directly measure the LNB or multi switch - done . ( All types of LNB)

The Satlink WS -7009 SE HD is also ideal for measurements in Unikabelanlagen . (Optional frequencies SCR)

The built-in battery makes this device an ultra - portable measuring instrument .

The unit displays the measured values ​​and generates the acoustic analysis of the signal intensity is also a tone signal search .

Measurement and presentation of the TV picture is possible HDTV DVB -S2 transponders + T2 !

SE Special WS- 7009 HD:

 TFT color LCD with a size of 4.3 "screen / 11cm
 backlit keyboard
 Taschenlampenfuktion ( White Power - LED on the back )
 HDMI 1.3a
 Audio and video input / output ( 3.5 mm jack )
 Spectrum Analyzer for DVB-S/S2 and DVB-T/T2
 SAT: QPSK 8PSK + + 16APSK for DVB-S/S2
 DVB -T: QPSK, 16QAM, 64QAM, 256QAM
 Measurements in HD transponder DVB- T + S possible
 Reception and playback + DVB-T/T2 DVB-S/S2 TV and TV HD image - and sound
 Allows measurements in satellite reception systems Unikabel
 Provides power for active DVB -T antenna
 Returns the 12V power supply for cameras A / V
 Nylon - Service - Case + Shoulder Strap

features:

Frequency range: 950 - 2150 MHz ( DVB- S ) + 48-862 MHz ( DVB -T)
built-in speaker
Calculation of azimuth , elevation and LNB tilt (after entering the coordination own data)
Indication of signal strength in percent and as bar
Viewing CBER
Shows S / N
Viewing SRM
The signal level shown in dBmV , dBmV and dBm
DiSEqC 1.0 control multiple switches or switches DiSEqC
1-16 Control DiSEqC LNB 1.1
DiSEqC 1.2 Motor control
Transponder scan and automatic channel scan TV + Radio
Blind scan function to search a complete satellite transponders for all assets
EPG ( Electronic Program Guide )
Select 4:3 or 16:9
AV Output: With the adapter cable, the device can connect to the TV and used as normal receiver
AV Input: for connecting external devices such as video cameras .

Data transfer via a USB memory :

- Firmware Updates
- Restore the custom settings
- Keep the satellites and edit on the PC
- Transmit satellite shows the device again
- Viewing pictures and playing MP3 files from USB memory
Storing and recalling its own system settings using USB memory stick


USB Memory: Display of photos stored in JPEG files and play MP3 music and your own USB memory format
3000mA / h LION -Power Battery for 1-6 hours of use!
