PIC18LF4680

PIC18LF4680 has a high computational performance at an economical price – with the addition of high-endurance, Enhanced Flash program memory. In addition to these features, the PIC18F4680 family introduces design enhancements that make these microcontrollers a logical choice for many high-performance, power sensitive applications.

Technical Specification

  • Program Memory Type: Flash
  • Program Memory Size (KB): 64
  • CPU Speed (MIPS/DMIPS): 10
  • SRAM Bytes: 3,328
  • Data EEPROM/HEF (bytes): 1024
  • Digital Communication Peripherals: 1-UART, 1-SPI, 1-I2C1-MSSP(SPI/I2C)
  • Capture/Compare/PWM Peripherals: 1 CCP, 1 ECCP
  • Timers: 1 x 8-bit, 3 x 16-bit
  • ADC Input: 11 ch, 10-bit
  • Number of Comparators: 2
  • Number of CAN Modules: 1 CAN
  • Temperature Range (C): -40 to 150
  • Operating Voltage Range (V): 2 to 5.5
  • Pin Count: 40
