NanoPi M1 plus All Winner H3 Quad-core ARM Cortex-A7 1.2 GHz

NanoPi M1 plus All Winner H3 Quad-core ARM Cortex-A7 1.2 GHz

Regular price ₦105,000.00 NGN
Regular price Sale price ₦105,000.00 NGN
Sale Sold out
Tax included. Shipping calculated at checkout.

Minicomputer NanoPi, version M1 Plus with processor Allwinner H3 quad-core ARM Cortex-A7 1.2 GHz. The board has 512M of DDR3 RAM, 8 GB of eMMC, built-in wi-fi and Bluetooth 4.0 module, a Ethernet Gigabit port, HDMI connector and two USB A slots + 1 x USB Host on 2.54 mm pins, 40 GPIOs, connector for microSD card. It works with the u-boot, Ubuntu Mate, Debian and Ubuntu-Core.





RAM Memory Installed Size :1 GB

CPU Speed: 1.2 GHz

Connectivity Technology: Wi-Fi, USB, Ethernet, HDMI

Operating System: Debian

CPU Manufacturer: Allwinner

three USB connectors,under which you can connect e.g. mouse, keyboard, WiFi card or flash drive. If it turns out that there are too few connections, you can increase their number usingan external USB HUB.

thernet socket, i.e. the possibility of direct connection to the LAN.

GPIO x 40 pin- general purpose outputs/inputs that can be used to operate LEDs, buttons, motor controllers. Among them there are pins supporting interfaces: I2C, SPI and UART.

microSD slot- slot for a microSD memory card, on which the operating system can be installed.

HDMI connector- transmits video to the monitor.
