20kg Load Cell Sensor

A 20kg Load Cell Sensor is a device used to measure weight or force. It is typically used in industrial applications such as weighing scales, force measurement, and load testing. The sensor is composed of a strain gauge, which is a device that measures the strain on an object when a force is applied. The strain gauge is connected to a Wheatstone bridge circuit, which converts the strain into an electrical signal. This signal is then amplified and converted into a digital signal, which can be read by a computer.

Technical Specifications

• Maximum Capacity: 20kg
• Output: 2mV/V
• Excitation Voltage: 5V
• Operating Temperature Range: -10°C to +40°C
• Accuracy: ±0.02%
• Non-Linearity: ±0.02%
• Hysteresis: ±0.02%
• Repeatability: ±0.02%
• Creep: ±0.02%
